AquaLine Drains Overview:

• Customization: Design and sizes can be customized. Middle and side outlets are available. All dimensions mentioned are in mm.
• Materials: All AquaLine products are made of high-quality materials such as SS304, SS316, and SS316L, offering a warranty of up to 20 years.
• Material Thickness: Ranges from 1mm to 2.5mm.

Product Range:

1. Shower Drain:
   • Available in various lengths: 300, 450, 600, 750, 900, 1000, and 1200 mm.
   • Standard dimensions for width and height are 70 mm (width) and 50 mm (height).
2. Tile Insert-Shower Drain:
   • Similar length options with a focus on seamless tile integration.
   • All options have a 70 mm width and 50 mm height.
3. Floor Drains:
   • Available in 2-piece and 3-piece designs.
   • Common dimensions include 200×200, 150×150, 125×125, 100×100, and 80×80 mm.
4. L-Shape Scupper Drain:
   • Made with a CI base and aluminum grate.
   • Dimension options include 160×160 mm base with various outlet sizes.
5. Dome Shaped-Roof Drain:
   • Made of CI material with sizes like 225 mm (A), 110 mm (B), and options for different outlet sizes.
6. Clean Out:
   • Available in sizes like 200×200, 150×150, 125×125, 100×100, and 80×80 mm.
   • Made from SS304/SS316/SS316L with a rubber gasket.
